In accordance with the ERTMS/ETCS specifications (mainly Subset 026 and ERA_ERTMS_015560 document), UIC 612 leaflet, EN 50126 series, EN 16186 series and EN 61375 series requirements, this document describes the Train Display System (TDS) in the driver’s cab which comprises the Train Display Controller (TDC) and the following six interfaces:
— Interface with Command Control Display (CCD);
— Interface with Train Radio Display (TRD);
— Interface with Electronic Timetable Display (ETD);
— Interface with Technical and Diagnostic Display (TDD);
— Interface with ETCS Onboard systems and the interfaced STMs, which is excluded from the scope of this document;
— Interface with Other Onboard Systems.

Product Details

Published:

04/24/2025

ISBN(s):

9780539327960

Number of Pages:

22

File Size:

1 file , 940 KB

Product Code(s):

30497821, 30497821, 30497821

Note:

This product is restricted and cannot be purchased in the following countries Ukraine, Russia, Belarus
